B120 Ceramic Blasting Media Zirconium Silicate Beads
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | Zirnano |
| Certification: | ISO9001,ISO14001 |
| Model Number: | B20-B505 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100kgs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 25KG BARREL+PALLET,2*12.5KG BARREL+CARTON+PALLET |
| Delivery Time: | 3-7 days after order confirmed |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 3000mts per year |
|
Detail Information |
|||
| Commodity: | Ceramic Blasting Media | Product Name: | Ceramic Beads |
|---|---|---|---|
| Color: | White | Shape: | Round Solid Beads |
| Main Chemical: | ZrO2 60-66%,Al2O3 7-13%,SiO2 25-30% | Usage: | Blasting Media |
| Hardness: | ≥700HV | Bulk Density: | 2.3g/cm3 |
| High Light: | B120 Zirconium Silicate Beads,Solid Zirconium Silicate Beads,Round Ceramic Blasting Media |
||
Product Description
Ceramic Blasting Media Zirconium Silicate Beads JZB120 JZB170 JZB205 for Computer Plastic Cladding
1. Product Description of Ceramic Blasting Media
Ceramic bead is also called as ceramic blasting media,it is one clean and high efficient blasting media,
which is widely used in blasting process for plastic parts,rubber parts,aluminium parts, titanium parts,
magnesium parts etc.
It has lower break-down rate,which will generate little dust in whole blasting process,it can replace glass
beads where one clean and bright working condition is required.
Compared with glass beads,the service life of ceramic beads will be prolonged 20-30 times, it is one ideal
and high efficient blasting media in blasting applications.
2. Main Technical Data
| Commodity | Main Chemical Index | Main Physical Index |
Ceramic Bead Blasting |
ZrO2 60-66% | Bulk Density: 2.3g/cm3 |
| SiO2 25-30% | True Specific Gravity: 3.85 g/cm3 | |
| Al2O3 7-13% | Hardness≥700HV | |
| Particle Size | Main Applications: | |
| B20: 0.600-0.850mm | Metal Surfce Shot Peening... | |
| B30: 0.425-0.600mm | ||
| B40: 0.250-0.425mm | Mold cleaning for glass bottle and tires... | |
| B60: 0.150-0.300mm | Stainless Steel outdoor fitness equipments | |
| B80: 0.125-0.212mm | Metal Finish for Aluminum Alloy parts | |
| B100: 0.106-0.180mm | Surface Finish for Titanium bicycle frame | |
| B120: 0.063-0.125mm | Surface Blasting for Golf club and airtifical joint | |
| B150:0.000-0.125mm | Surface Finish for 3C metal frame | |
| B170: 0.045-0.090mm | Surfce Finish for 3C metal shell | |
| B205: 0.000-0.063mm | Computer plastic cladding,Fishing Gear... | |
| B400: 0.030-0.063mm | Metallic Surface Finsh for Satiny Blasting Effect | |
| B505: 0.010-0.030mm | ||
| Remark: Special specification can be customized | ||
3. Main Packages
25kg round barrel+ Pallet
2*12.5kg barrel+ Carton+ Pallet
25kg round barrel+ Wooden Case
4. How to Judge the quality of Ceramic Beads?
Sphericity is the most direct way to judge the quality of ceramic beads,qualified ceramic beads has higher
sphericity(length/width rate:0.80) over 85%.
Cleanliness is also one important factor affects the quality of ceramic beads. It is easy to judge the cleanliness
of ceramic beads, just put ceramic beads into clean water,then the ceramic beads with higher cleanliness will
sink to the bottom of container and the water is cleaner,not muddy.
Color and particle size is still important factors to judge the quality of ceramic beads. Good ceramic beads has
white color and more uniform particle size distribution,which can be judged easily from the product appearance.
5. Why choose us?
Professional manufacturer of ceramic blasting media,annual output over 3000mts
More competitive price/performance ratio.
Strict production formula and quality control system;
All the products will be sampled twice even for one small free sample;
Diverse and flexible package to meet clients’ different requirements;
Fast Delivery and flexible payment methods;
Stable supplier of world famous enterprises: Foxconn,Samsung Electronics...
