High Spheroidality Ceramic Bead Blasting Media B205 good roundness
Product Details:
| Place of Origin: | China |
| Brand Name: | Zhengtong |
| Certification: | ISO9001,ISO14001 |
| Model Number: | B20-B505 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100KGS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 2*12.5kg barrel+ carton box + pallet or 25kg barrel+pallet |
| Delivery Time: | 3-5 days after order confirmed |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 200mts per month |
|
Detail Information |
|||
| Commodity: | Ceramic Blasting Beads | Product Name: | Ceramic Blasting Media |
|---|---|---|---|
| Usage: | Surface Finish For 3C Products | Bulk Density: | 2.3 G/cm3 |
| True Gravity: | 3.85 G/cm3 | Vicker Hardness: | 700 HV |
| Main Material: | 62-66% ZrO2 | Shape: | Solid Round Ball |
| High Light: | abrasive blasting media,ceramic bead blasting media |
||
Product Description
High Spheroidality Ceramic Bead Blasting Media B205 good roundness
Description
Ceramic blasting beads is spherical micro beads, with good roundness, is the main blasting media for
Aluminum alloy die-casting parts, zinc alloy die-casting parts to deburr edges and sandblasting finishing,
usually applicable for USB Disks shells, USB data cable interface, etc.
| Ceramic Beads Technical Data | |||
| Components | Content | CAS No. | EC No. |
| ZrO2 (Zirconium dioxide) | 60-68% | 1314-23-4 | 215-227-2 |
| SiO2 (Silicon dioxide) | 25-30 | 60676-86-0 | 262-373-8 |
| Al2O3 (Aluminum oxide ) | 7-13% | 1344-28-1 | 215-691-6 |
| Manufacturing Method | Melting in above 2000℃ furnace | ||
| True Density | 3.85 g/cm3 | ||
| Bulk Density | 2.3g/cm3 | ||
| Vicker Hardness | 700HV | ||
| Sizes for Sand Blasting | |||
| Bead Size | Size range | Bead Size | Size range |
| B20 | 0.60-0.85 mm | B120 | 0.063-0.125 mm |
| B30 | 0.425-0.60 mm | B125 | 0.000-0.125 mm |
| B40 | 0.24-0.425 mm | B170 | 0.045-0.090 mm |
| B60 | 0.125-0.25 mm | B205 | 0.000-0.063 mm |
| B80 | 0.18-0.25 mm | B400 | 0.030-0.063 mm |
| B100 | 0.125-0.18 mm | B505 | 0.000-0.030 mm |
| Sizes for Shot Peening | |||
| Z850 | 0.85-1.18 mm | Z210 | 0.21-0.30 mm |
| Z600 | 0.6-0.85 mm | Z150 | 0.15-0.21 mm |
| Z425 | 0.425-0.60 mm | Z100 | 0.10-0.15 mm |
| Z300 | 0.30-0.425 mm | ||
Features
- Impact resistance, long service life;
- Small dust, good sandblasting effect;
- Smooth surface, good fluidity;
- Low wear, low nozzle loss;
- Very low iron content, no pollution of the workpiece.
- Can be recycle for many times use, high cost performance.
Application
DEBURRING & BLASTING FINISH
- Alu Alloy Die-casting parts like USB discs
- Zinc Alloy Die-casting parts like USB data cable interface.
- Sandblasting to deburr and surface treatment finish of Matte metal luster.
Package
- 25kgs-12L Barrels
- 12.5kgs small Barrels, 2 barrels in Paper cartons
Lot number is the production date
Label
Labeling on the barrels and paper cartons
Net weight: Net 25kg
Supply packaging picture
- Custody method
Quality guarantee period
2 years after delivery.
Keep the barrels sealed in order to prevent impurities mixing.
Avoid direct sunlight
Store in a dry and cool warehouse
Keep ventilated
Far from fire
If you're looking for ceramic beads B205, contact us to get more details and updated price.
No matter big or small quantity, or even samples or sample orders, you will get professional and patient service.
