White Ceramic Blasting Media Shot Peeing Zirconia Beads Z850 For Automotive Industries
Product Details:
| Place of Origin: | China |
| Brand Name: | Zirnano |
| Certification: | ISO9001,ISO14001 |
| Model Number: | Z100-Z850 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100KGS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 2*12.5kg Barrel+ Carton Box+Pallet,25kg Barrel+Pallet |
| Delivery Time: | 3-5 days after order confirmed |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 3000 MTS per Year |
|
Detail Information |
|||
| Commodity: | Ceramic Shot Peening | Product Name: | Ceramic Beads |
|---|---|---|---|
| Chemical Composition: | 62-66% ZrO2 | Bulk Density: | ≥2.3 G/cm3 |
| Vicker Hardness: | ≥700HV | Color: | White |
| High Light: | bead blasting material,ceramic bead blasting media |
||
Product Description
Ceramic Shot Peeing Zirconia Beads Z850,Z600,Z425,Z300,Z210,Z150,Z100 for Automotive Industries
1. Product Description of Ceramic Shot Peening
Ceramic shot peening is one of the most widely used processes for improving the wear properties of metal
surfaces,it will improve the fatigue life and mechnical strength of metal surfaces greatly.
Ceramic shot peening has high hardness,high density,low breakdown rate, good sphericity,smooth surface,
it is the ideal media for shot peening.All Zirnano Ceramic shot peening is screened by six times and blow-cleaned
in high termperature,ensuring the high cleanliness,it is able to normally work in humid weather.
2. The main technical data of ceramic shot peening as below:
| Item | Ceramic Blasting Beads |
| Chemical Index | ZrO2 60-66% SiO2 25-30% Al2O3 7-13% |
| Vickers Hardness | ≥700 HV |
| True Specific Gravity | ≥3.85 g/cm3 |
| Particle Size | 100-1180μm |
| Usage | Shot Peening |
| Particle Size | |||
| Z100 | Z150 | Z210 | Z300 |
| 100-150μm | 150-210μm | 210-300μm | 300-425μm |
| Z425 | Z600 | Z850 | |
| 425-600μm | 600-850μm | 850-1180μm | |
3. Main Features of Ceramic Shot Peening
- High hardness and low breakdown rate
Ceramic shot peening has high vicker hardness over 700HV and low breakdown rate,it can be used for shot
peening for hard steel, titanium and aluminum,when sprayed on the metal surface,high energy at the impact
point on the metallic substrate will be transferred,it will keep the integrity of peened surface and achieve
smooth and uniform surface finish;
- High efficiency,long service life
Ceramic Shot peening contains 62-66% ZrO2,its fine microstructure ensures it is not easy to be breakdown in
the peening process,people do not need to refuel the new beads frequently,it will save the refuel time and
improve the blasting effciency.Ceramic shot peening can be recycled 70-90 times,its service life has been
prolonged compared with other abrasives.
- No contamination with the external materials
Ceramic shot peening is one kind of ceramic material, it is not easy to get the physical and chemical reactions
with the external materials, which remians clean and bright surface.
- No hidden danger of Silicosis
There is little dust generated in shot peening process,providing a clean working condition and good peening
sight for the worker,also ensures the workers to be escaping from the hidden danger of silicosis.
4. Main Applications of Ceramic Shot Peening:
- Shot peening formechnical components made by metallic alloys such as hard steel,titanium,aluminum..
to enhance the fragile resistance;
- Shot Forming for aerospace structural components to shape and strengthen its slim hard alloys.
5. Why Choose Us?
Professional Manufacturer of ceramic beads,annual output over 3000mts;
Equipped the most advanced production line,testing equipment, as well as professional technical staffs;
Strict quality control and quality assurance, products will be inspected by eachShipment,even for the free
sample in small quantity;
Multiple Authentication,Certificated by ISO9001 ISO14001,SGS,ROHS;
Stable supplier of Foxconn,Ujiden,Samsung Electronics,Tongda Group etc.
Products in good quality & stable performance,competitive price,flexible payment terms.
