White Ceramic Blasting Media Shot Peeing Zirconia Beads Z850 For Automotive Industries

White Ceramic Blasting Media Shot Peeing Zirconia Beads Z850 For Automotive Industries

Product Details:

Place of Origin: China
Brand Name: Zirnano
Certification: ISO9001,ISO14001
Model Number: Z100-Z850

Payment & Shipping Terms:

Minimum Order Quantity: 100KGS
Price: Negotiable
Packaging Details: 2*12.5kg Barrel+ Carton Box+Pallet,25kg Barrel+Pallet
Delivery Time: 3-5 days after order confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 3000 MTS per Year
Get Best Price Contact Now

Detail Information

Commodity: Ceramic Shot Peening Product Name: Ceramic Beads
Chemical Composition: 62-66% ZrO2 Bulk Density: ≥2.3 G/cm3
Vicker Hardness: ≥700HV Color: White
High Light:

bead blasting material

,

ceramic bead blasting media

Product Description



Ceramic Shot Peeing Zirconia Beads Z850,Z600,Z425,Z300,Z210,Z150,Z100 for Automotive Industries



1. Product Description of Ceramic Shot Peening

Ceramic shot peening is one of the most widely used processes for improving the wear properties of metal

surfaces,it will improve the fatigue life and mechnical strength of metal surfaces greatly.

Ceramic shot peening has high hardness,high density,low breakdown rate, good sphericity,smooth surface,

it is the ideal media for shot peening.All Zirnano Ceramic shot peening is screened by six times and blow-cleaned

in high termperature,ensuring the high cleanliness,it is able to normally work in humid weather.



2. The main technical data of ceramic shot peening as below:



Item Ceramic Blasting Beads
Chemical Index ZrO2 60-66%
SiO2 25-30%
Al2O3 7-13%
Vickers Hardness ≥700 HV
True Specific Gravity ≥3.85 g/cm3
Particle Size 100-1180μm
Usage Shot Peening





Particle Size
Z100 Z150 Z210 Z300
100-150μm 150-210μm 210-300μm 300-425μm
Z425 Z600 Z850
425-600μm 600-850μm 850-1180μm



3. Main Features of Ceramic Shot Peening

  • High hardness and low breakdown rate

Ceramic shot peening has high vicker hardness over 700HV and low breakdown rate,it can be used for shot

peening for hard steel, titanium and aluminum,when sprayed on the metal surface,high energy at the impact

point on the metallic substrate will be transferred,it will keep the integrity of peened surface and achieve

smooth and uniform surface finish;



  • High efficiency,long service life

Ceramic Shot peening contains 62-66% ZrO2,its fine microstructure ensures it is not easy to be breakdown in

the peening process,people do not need to refuel the new beads frequently,it will save the refuel time and

improve the blasting effciency.Ceramic shot peening can be recycled 70-90 times,its service life has been

prolonged compared with other abrasives.



  • No contamination with the external materials

Ceramic shot peening is one kind of ceramic material, it is not easy to get the physical and chemical reactions

with the external materials, which remians clean and bright surface.



  • No hidden danger of Silicosis

There is little dust generated in shot peening process,providing a clean working condition and good peening

sight for the worker,also ensures the workers to be escaping from the hidden danger of silicosis.



4. Main Applications of Ceramic Shot Peening:

  • Shot peening formechnical components made by metallic alloys such as hard steel,titanium,aluminum..

          to enhance the fragile resistance;



  • Shot Forming for aerospace structural components to shape and strengthen its slim hard alloys.



White Ceramic Blasting Media Shot Peeing Zirconia Beads Z850 For Automotive Industries 0

5. Why Choose Us?



Professional Manufacturer of ceramic beads,annual output over 3000mts;



Equipped the most advanced production line,testing equipment, as well as professional technical staffs;



Strict quality control and quality assurance, products will be inspected by eachShipment,even for the free

sample in small quantity;



Multiple Authentication,Certificated by ISO9001 ISO14001,SGS,ROHS;



Stable supplier of Foxconn,Ujiden,Samsung Electronics,Tongda Group etc.



Products in good quality & stable performance,competitive price,flexible payment terms.
