Ceramic Beads B60 Zirconia Beads Casting Forged Welded Heat Treated Sandblast Clean

Ceramic Beads B60 Zirconia Beads Casting Forged Welded Heat Treated Sandblast Clean

Product Details:

Place of Origin: Shanxi, China
Brand Name: Zhengtong
Certification: ISO9001, ISO14001
Model Number: B60

Payment & Shipping Terms:

Minimum Order Quantity: 100KGS
Price: Negotiation
Packaging Details: 12.5kgs/barrel, 25kgs (2 barrels)/paper carton, or 25kgs barrels +pallet
Delivery Time: 5-10 days
Supply Ability: 1500mt per year
Get Best Price Contact Now

Detail Information

Commodity Name: Ceramic Beads Blasting Media Chemical Index: ZrO2 60-66%, SiO2 25-30%, Al2O3 7-13%
Manufacturing Process: Melting Method Bulk Density: 2.3g.cm3
True Density: 3.85g/cm3 Hardness: 700HV
Package: 25kgs Paper Cartons Or 25kgs Barrels +pallet
High Light:

bead blasting material

,

ceramic bead blasting media

Product Description



Ceramic beads blasting media B60 for Casting forged welded heat-treated blast clean



DESCRIPTION



The ceramic beads are made of zirconium sand mineral through electric fusion, with fine internal structure of zirconium crystals in a glassy silicon dioxide cover, thus have high density and high impact resistance features.

It’s high quality blasting media, suitable for surface cleaning and deburring, and precise surface treatment on stainless steel, non-ferrous metals, and Aluminum alloy work pieces, etc..



SPECIFICATION



Chemical Index ZrO2 SiO2 Al2O3
60-65% 25-30% 7-13%
Typical Value 62.20% 26.10% 9.05%
Bulk Density 2.3g/cm3
Specific Density 3.85g/cm3
Vickers Hardness 700HV



Sizes

B20 B30 B40 B60
600-850µm 425-6000µm 0250-425µm 125-250µm
B80 B120 B170 B205
180-250µm 63-125µm 45-90µm 0-63µm

Special sizes available against clients’ requirement.





FEATURES



Our ceramic beads is of top quality in China, and has below features

1) Imported raw materials, High quality ceramic beads

Use Australia imported high-quality raw materials to produce ceramic beads, high hardness, good elasticity and higher service life.



2) Independent research and development

Complete product testing equipment and complete independent intellectual property rights, as well as independent laboratories and university cooperative laboratories in Beijing and Shijiazhuang.

More importantly, we have years of continuous improvement in R&D team.



3. Better cleanliness and sizes more concentration

We have our own particle sizes distribution standard, with more concentration granules and can screen as per clients’ requirement.



4. High hardness, long life and good elasticity

The hardness of ceramic beads is high,and the deformation is small.

The hardness of ceramic sand can 700 HV, it ensures that ceramic bead can be shot peened for high strength and high strength structural parts. Small deformation ensures that the shape of the projectile does not change during impact, and the spherical shape of the ceramic sand improves the quality stability of the shot peening of the part.



APPLICATION



Casting and forging parts, welded parts, heat-treated parts - Sandblast Cleaning

Ceramic beads sand blasting can clean all the dirt on the surface of the casting, forging and welding workpiece , such as oxide scale and oil stain, and polish the surface of the workpiece to improve the smoothness , and to beautify the work piece surface.

Sand blasting can make the workpiece exposed uniform metallic color, making the appearance of the workpiece more beautiful.



Ceramic Beads B60 Zirconia Beads Casting Forged Welded Heat Treated Sandblast Clean 0

Other application like Sandblasting finishing, Surface cleaning, Surface Pretreatment and Renovation of old work parts etc..





APPLICABLE EQUIPMENT



Suitable sand blasting machine:

Manual sand blasting machine, Automatic sand blasting machine,

Open type series of sand blasting machine, and Blasting room series.
