Product Details:

Place of Origin: China
Brand Name: Zirnano
Certification: ISO9001,ISO14001
Model Number: Z100-Z850,B20-B400

Payment & Shipping Terms:

Minimum Order Quantity: 100KGS
Price: Negotaible
Packaging Details: 2*12.5 KGS Barrel +Carton Box + Pallet,25KGS Barrel + Pallet
Delivery Time: 3-5 days after order confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 3000mts
Get Best Price Contact Now

Detail Information

Commodity: Zirconia Shot Peening Product Name: Ceramic Bead Blasting
Usage: Shot Peening Process: Melting Process
Shape: Solid Round Ball Recycles: 70-90
High Light:

Z100 Zirconia Shot Peening

,

Zirconia Shot Peening Aerospace Industry

,

Aerospace Industry Ceramic Cleaning Media

Product Description

Ceramic Bead Blasting Zirconia Shot Peening Z850-Z100 for Aerospace Industry

1. Product Description of Ceramic Bead Blasting Zirconia Shot Peening

Zirnano Ceramic Shot Peening contains 60-66% ZrO2,it is featured with high hardness,high strength impact and high toughness,its solid round shape and tight particle size distribution,ensures its wide application in aerospace and automotive industry.



It has tight particle size distribution as below:

Z100 Z150 Z210 Z300
100-150μm 150-210μm 210-300μm 300-425μm
Z425 Z600 Z850
425-600μm 600-850μm 850-1180μm



2. Main Technical Data of Zirconia Shot Peening:

Commodity Main Chemical Index Main Physical Index
Ceramic Beads ZrO2 60-66% Bulk Density: 2.3g/cm3
SiO2 25-30% True Specific Gravity: 3.85 g/cm3
Al2O3 7-13% Vickers Hardness: 700 HV



3. Why Ceramic Beads is widely used as shot peening media?

Good sphericity, smooth surface, providing the minimal crack initiation.



Good elasticity,high hardness,it will be rebunded in multi-angles in the peening process,it is able to cover

the intricate geometries homogeneously,finally achieving the consistent visual effect;



Ceramic beads has zero ferrous contaminations to the treatment;



Ceramic beads has high hardness and good impact resistance,when sprayed on the metal surface in high

speed,the impacted surface and the underlying metal material are plastically deformed and extended,finally

extend the fatigue life and corrosion resistance.



Therefore ceramic beads is widely used as one shot peening media.



4. Main applications of Ceramic Shot Peening:

Shot peening for metal parts in aerospace industry to improve the surface strength,eliminate the stress,reduce

the metal weights;

Shot peening in automotive industry such as gearbox gears,automotive aluminum hubs etc. to extend the

anti-fatigue life.


5. Why Choose Us?

Professional Manufacturer of ceramic beads,annual output over 3000mts

Equipped the most advanced production line,testing equipment, as well as professional technical staffs;

Strict quality control and quality assurance, products will be inspected by each

Shipment,even for the free sample in small quantity;

Multiple Authentication,Certificated by ISO9001 ISO14001,SGS,ROHS;

Stable supplier of Foxconn,Ujiden,Samsung Electronics,Tongda Group etc

Products in good quality & stable performance,competitive price,flexible payment terms.

6. How to calculate the media Blasting cost?

People always need the right blasting media with best price/performance ratio,here we simply state how

to calculate the media cost,details as below:



Media Blasting Cost
Media Name Cycles %Breakdown
Glass Beads 9-12 10%
Ceramic Beads 70-90 1.20%
Steel shot 80-100 1%
Media Cost Per Hour=Hourly Delivery Rate*%Breakdown*cost per Lb.
Media Cost to Blast a Part=Media Cost Per Hour*Part cycle time(% of Hour)
