Ceramic Blasting Beads B120 Multi Sizes Lead Different Roughness

Minimum Order Quantity : 100KGS Price : Negotiable
Packaging Details : 2*12.5kg barrel+ carton box + pallet or 25kg barrel+pallet Delivery Time : 3-5 days after order confirmed
Payment Terms : L/C, T/T, Western Union, MoneyGram Supply Ability : 200mts per month
Place of Origin: China Brand Name: ZIRNANO
Certification: ISO9001,ISO14001 Model Number: B20-B505

Detail Information

Commodity: Ceramic Blasting Beads Product Name: Ceramic Blasting Media
Usage: Surface Finish For 3C Products Bulk Density: 2.3 G/cm3
True Gravity: 3.85 G/cm3 Vicker Hardness: 700 HV
Main Material: 62-66% ZrO2 Shape: Solid Round Ball
High Light:

low dust blasting media


ceramic cleaning media

Product Description

Ceramic Beads B120 blasting media multi sizes leading different roughness




Ceramic beads is one of popular sand blasting media for metal surface treatment, and the sandblasting is

the more thorough, more versatile, faster, and more efficient cleaning and surface treatment method.

Using ceramic beads as the blasting meida, is arbitrarily chosen between different roughnesses, and other

processes have no way to achieve this.


Technical Data
Components Content CAS No. EC No.
ZrO2 (Zirconium dioxide) 60-68% 1314-23-4 215-227-2
SiO2 (Silicon dioxide) 25-30 60676-86-0 262-373-8
Al2O3 (Aluminum oxide ) 7-13% 1344-28-1 215-691-6
Manufacturing Method Melting in above 2000℃ furnace
True Density 3.85 g/cm3
Bulk Density 2.3g/cm3
Vicker Hardness 700HV
Sizes for Sand Blasting
Bead Size Size range Bead Size Size range
B20 0.60-0.85 mm B120 0.063-0.125 mm
B30 0.425-0.60 mm B125 0.000-0.125 mm
B40 0.24-0.425 mm B170 0.045-0.090 mm
B60 0.125-0.25 mm B205 0.000-0.063 mm
B80 0.18-0.25 mm B400 0.030-0.063 mm
B100 0.125-0.18 mm B505 0.000-0.030 mm
Sizes for Shot Peening
Z850 0.85-1.18 mm Z210 0.21-0.30 mm
Z600 0.6-0.85 mm Z150 0.15-0.21 mm
Z425 0.425-0.60 mm Z100 0.10-0.15 mm
Z300 0.30-0.425 mm




Characteristics of metal surface blasting process with Ceramic beads:


1. To sandblast with ceramic beads as media, the flexibility of cleaning is large. It is easy to clean the inner and outer surfaces of the complex workpiece and the inner wall of the pipe; and it is not restricted by the site, it can be moved to the vicinity of the extra large workpiece for cleaning.


2. Ceramic beads blasting consumes smaller energy comparing with steel balls.


3. The ceramic bead blasting equipment structure is simple, the investment of the whole machine is less, the wearing parts are less, and the maintenance cost is low.


4. Metal surface blasting process with ceramic beads media has high cleaning efficiency.


5. Other wet clean ways is easy to have moisture, easy to embroider.



  • 3C industry sandblasting: Computer shell, mobile phone middle frame, built-in parts and USB Data cable plug blasting surface treatment.
  • Glass bottle & Tires Molds cleaning sandblasting
  • Shot peening in automotive and aerospace industry.
  • Metal work pieces surface treatment blasting finish, like Hard wares parts, Pots, medical instrument, golf club, etc

Ceramic Blasting Beads B120 Multi Sizes Lead Different Roughness 0




If  you need ceramic beads sandblasting media or shot peening media, please don't hesitate to contact us.


Every inquiry will be responsed fastly.
