Size 0.85 - 1.18 Mm Z850 Ceramic Shot Peening To Prevent Material Fatigue
Product Details:
| Place of Origin: | Shanxi, China |
| Brand Name: | Zirnano |
| Certification: | ISO9001, ISO14001 |
| Model Number: | Z100, Z150,Z210,Z300,Z425,Z600,Z850 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100KGS |
|---|---|
| Price: | Negotiation |
| Packaging Details: | 12.5kgs/barrel, 25kgs (2 barrels)/paper carton, or 25kgs barrels +pallet |
| Delivery Time: | 5-10 days |
| Supply Ability: | 1500mt per year |
|
Detail Information |
|||
| Commodity Name: | Ceramic Beads Blasting Media | Chemical Index: | ZrO2 60-66%, SiO2 25-30%, Al2O3 7-13% |
|---|---|---|---|
| Manufacturing Process: | Melting Method | Bulk Density: | 2.3g.cm3 |
| True Density: | 3.85g/cm3 | Hardness: | 700HV |
| Package: | 25kgs Paper Cartons Or 25kgs Barrels +pallet | ||
| High Light: | shot blasting material,shot blasting abrasive,abrasive shot blasting |
||
Product Description
Size 0.85-1.18 mm Ceramic Shot Z850 shot peening to prevent material fatigue
The ceramic shot peening media is also called as ceramic beads, the main chemical composition is 60-66%
ZrO2 ,its fine microstructure ensures its high hardness,high toughness.
It also has the wide particle size from Z100 t0 Z850.The spherical shape also determines to be one ideal
shot peening.
Shot peening is a cold working process in which a small steel, ceramic or glass media propel at a relatively
high speed to hammer the surface of the material. These shot particles form a series of overlapping pits on
the surface of the material, and compress the upper layer of the material and help prevent material fatigue failure.
Compared with steel shot, ceramic shot peening will not generate new ferrous contamination to the treatment surface,
It is able to replace the steel shot where ferrious contamination is prohibited.
| Chemical Index | ZrO2 | SiO2 | Al2O3 |
| 60-65% | 25-30% | 7-13% | |
| Typical Value | 62.20% | 26.10% | 9.05% |
| Bulk Density | 2.3g/cm3 | ||
| Specific Density | 3.85g/cm3 | ||
| Vickers Hardness | 700HV | ||
| Bead Size (mm) | Z100 | 0.10-0.15 | |
| Z150 | 0.15-0.21 | Z425 | 0.425-0.6 |
| Z210 | 0.21-0.30 | Z600 | 0.6-0.85 |
| Z300 | 0.30-0.425 | Z850 | 0.85-1.18 |
Special sizes available against clients’ requirement.
-
1. High Density, not only applicable for shot peening of low-strength structural parts, but also can shot peening for high-strength structural parts.
-
2. Smooth surface, high sphericity, and good elasticity, can protect the equipment, whether it is dry or wet spray.
-
3. Can strengthen the surface of the metal surface, improve the service life of the workpiece, improve the wear resistance, and improve the texture of the workpiece.
-
4. Variety of grade, or size, of the ceramic shot to provide the required surface finish and strength compression.
-
5. Applicable to finish many metals, including aluminum, steel, steel forgings and machine parts.
- Used for surface strengthening treatment of precision casting parts such as aircraft turbine blades and shafts, ordnance, and various spring gear hydraulic parts to eliminate internal stress.
- Used in the automotive industry for strengthening treatment to the surface of Shock absorber spring to improve its anti-fatigue performance
- Shot peening of gears, machined tools and other metal /alloy parts to eliminate stress and increase surface strength
Robot Shot Peening System
CNC Shot Peening Machine
Automatic Shot Peen System
Rotary Shot Peening System
Lean Turbine Blade Root Peen
Our Service
Free Samples -1kgs
Different blasting workpieces, Different requirements for ceramic beads.
Our factory can provide consult solution, suggest the ceramic beads sizes according to the workpiece you handle and provide 1kgs ceramic beads samples for free.
OEM customize same ceramic beads with your samples or requirements.
Our factory has our own test lab., with high precision chemical and particle size detection instruments. You can send ceramic beads samples, then we will test and analysis it and customize same ceramic beads with your samples or according to your customer requirements.
Quality Guarantee
Guarantee our ceramic beads has no quality problems, and in case any problems are found,
We accept return and/or exchange.
If you're looking for ceramic shot peening media, just feel free to contact us to get advisory pre-sale service, best price and sample. etc.
