High Toughnes Ceramic Polishing Media Zirconia Sand B20 - B205 For Surface Finish

High Toughnes Ceramic Polishing Media Zirconia Sand B20 - B205 For Surface Finish

Product Details:

Place of Origin: China
Brand Name: Zirnano
Certification: ISO9001,ISO14001
Model Number: B20-B400

Payment & Shipping Terms:

Minimum Order Quantity: 100KGS
Price: Negotiable
Packaging Details: 2*12.5kg barrel+ carton box + pallet or 25kg barrel+pallet
Delivery Time: 3-5 days after order confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 200mts per month
Get Best Price Contact Now

Detail Information

Commodity: Ceramic Bead Blasting Product Name: Ceramic Blasting Media
Usage: Surface Finish For 3C Products Bulk Density: 2.3 G/cm3
True Gravity: 3.85 G/cm3 Vicker Hardness: 700 HV
Main Material: 62-66% ZrO2 Shape: Solid Round Ball
High Light:

abrasive media blasting

,

ceramic cleaning media

Product Description

High Toughnes Ceramic Bead Blasting Zirconia Sand B20-B205 for surface Finish of Light Alloy or Metal Parts

1. Product Description of Ceramic Bead Blasting

Ceramic bead contains 60-66% ZrO2,so it is also called as Zirconia sand,it is one solid ball,which is melting

and blending in electric furnace under high temperature more than 2000 degree by special technology.

Ceramic bead has wide particle size,it could be matched with various blasting equipment,so it is one popular

blasting media in many applications.



2.The camparation between Ceramic Beads & Glass Beads

Ceramic bead and glass bead both has round and solid shape, as well as no ferrous contamination to the

workpieces,but they are two different blasting media.

Hereby we make a simple comparation between them as below:

Item Ceramic Blasting Beads Glass Beads
Chemical Index ZrO2 60-66%
SiO2 25-30%
Al2O3 7-13%
SiO2:>65%,Na2O<14.0%
CaO>8.0%,MgO>2.5%
Al2O3 0.5-2.0% Fe2O3:0.15%


Vickers Hardness ≥700 HV ≥560HV
True Specific Gravity ≥3.85 g/cm3 ≥2.5g/cm3
Bulk Density ≥2.3g/cm3 ≥1.5g/cm3
Particle Size 0.030-0.850mm 0.045-0.85mm
Usage Blasting Media Blasting Media
Ferrous Contamination No Ferrous No Ferrous
Dust Pollution Little Large
Recyclable Times Multiple One time or twice
Power consumption Low Low
Service Life Long 1/25 of ceramic beads
Equipment Wear Rate Low Low
Blasting Effect High finish
No discoloration
High finish
White discoloration



The Comparation of Particle Size
Ceramic Beads Glass Beads
B20: 0.600-0.850mm 30#:0.400-0.800mm
B30:0.425-0.600mm
B40:0.250-0.425mm 60#:0.200-0.400mm
B60:0.125-0.250mm 80#:0.150-0.250mm
B80:0.180-0.250mm 100#:0.100-0.200mm
B100:0.125-0.180mm 120#:0.100-0.150mm
B120:0.063-0.125mm 150#:0.070-0.150mm
180#:0.070-0.110mm
B170:0.045-0.090mm 220#:0.050-0.100mm
B205:0.045-0.063mm 280#:0.040-0.070mm
B400:0.030-0.063mm 320#:0.001-0.050mm



Seen from the above chart, we know ceramic bead has the advantages of higher hardness, low dust generation,

longer service life,better blasting effect in visual sight compared with the one of glass beads,so ceramic beads

can replace galss beads where requires a clean and better blasting effect.



3. Product Features of Zirnano Ceramic Bead Blasting

Higher clearliness

Our ceramic bead are screened more than six times and blow-cleaning under high temperature,

which provides higher clearliness and ensures it to be work normally in humid weather;



More concentrated particle size distribution

B170(0.045-0.090μm),B205(0.045-0.063μm) is more concentrated than the other one(0-0.063μm) from other

company,which will achieve better blasting effect.



4. Main Applications of Ceramic Beads

B20&B30:Surface Sandblasting for metal Surface;

B40:Mold cleaning for glass bottles;

B60: surface cleaning for inner or outter wall of precision steel pipes;

B120: Surface finish for Golf club and artifical joint etc.

B170&B205: Surface finish for the metal surface of Iphone,Ipad,Ipod;

For more applications,please kindly review our other products of ceramic bead blasting.

High Toughnes Ceramic Polishing Media Zirconia Sand B20 - B205 For Surface Finish 0



5. Applicable Equipments:

Manual sand blasting machine;

Automatic sand blasting machine;

Open sand blasting machine;

Sandblasting room.

6. Why choose us?

Professional manufacturer of ceramic beads to provide stable products with most favorable price

Certificated by ISO9001,ISO14001

Products has already exported to Japan,Vietnam, USA, Russia,Poland,Taiwan Area etc.

The stable supplier of Foxconn,Samsung Electronics,Tongda Group etc.

7. How to use & store ceramic beads?

When using the ceramic beads,please wear protective equipments appropriately;

Avoid direct contact with eyes and skin;

Please wash hands with water and soap before eating, drinking and smoking;

Keep the container tightly closed and store it in a cool, dry warehouse
