High Toughnes Ceramic Polishing Media Zirconia Sand B20 - B205 For Surface Finish
Product Details:
| Place of Origin: | China |
| Brand Name: | Zirnano |
| Certification: | ISO9001,ISO14001 |
| Model Number: | B20-B400 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100KGS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 2*12.5kg barrel+ carton box + pallet or 25kg barrel+pallet |
| Delivery Time: | 3-5 days after order confirmed |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 200mts per month |
|
Detail Information |
|||
| Commodity: | Ceramic Bead Blasting | Product Name: | Ceramic Blasting Media |
|---|---|---|---|
| Usage: | Surface Finish For 3C Products | Bulk Density: | 2.3 G/cm3 |
| True Gravity: | 3.85 G/cm3 | Vicker Hardness: | 700 HV |
| Main Material: | 62-66% ZrO2 | Shape: | Solid Round Ball |
| High Light: | abrasive media blasting,ceramic cleaning media |
||
Product Description
High Toughnes Ceramic Bead Blasting Zirconia Sand B20-B205 for surface Finish of Light Alloy or Metal Parts
1. Product Description of Ceramic Bead Blasting
Ceramic bead contains 60-66% ZrO2,so it is also called as Zirconia sand,it is one solid ball,which is melting
and blending in electric furnace under high temperature more than 2000 degree by special technology.
Ceramic bead has wide particle size,it could be matched with various blasting equipment,so it is one popular
blasting media in many applications.
2.The camparation between Ceramic Beads & Glass Beads
Ceramic bead and glass bead both has round and solid shape, as well as no ferrous contamination to the
workpieces,but they are two different blasting media.
Hereby we make a simple comparation between them as below:
| Item | Ceramic Blasting Beads | Glass Beads |
| Chemical Index | ZrO2 60-66% SiO2 25-30% Al2O3 7-13% |
SiO2:>65%,Na2O<14.0% CaO>8.0%,MgO>2.5% Al2O3 0.5-2.0% Fe2O3:0.15% |
| Vickers Hardness | ≥700 HV | ≥560HV |
| True Specific Gravity | ≥3.85 g/cm3 | ≥2.5g/cm3 |
| Bulk Density | ≥2.3g/cm3 | ≥1.5g/cm3 |
| Particle Size | 0.030-0.850mm | 0.045-0.85mm |
| Usage | Blasting Media | Blasting Media |
| Ferrous Contamination | No Ferrous | No Ferrous |
| Dust Pollution | Little | Large |
| Recyclable Times | Multiple | One time or twice |
| Power consumption | Low | Low |
| Service Life | Long | 1/25 of ceramic beads |
| Equipment Wear Rate | Low | Low |
| Blasting Effect | High finish No discoloration |
High finish White discoloration |
| The Comparation of Particle Size | |
| Ceramic Beads | Glass Beads |
| B20: 0.600-0.850mm | 30#:0.400-0.800mm |
| B30:0.425-0.600mm | |
| B40:0.250-0.425mm | 60#:0.200-0.400mm |
| B60:0.125-0.250mm | 80#:0.150-0.250mm |
| B80:0.180-0.250mm | 100#:0.100-0.200mm |
| B100:0.125-0.180mm | 120#:0.100-0.150mm |
| B120:0.063-0.125mm | 150#:0.070-0.150mm |
| 180#:0.070-0.110mm | |
| B170:0.045-0.090mm | 220#:0.050-0.100mm |
| B205:0.045-0.063mm | 280#:0.040-0.070mm |
| B400:0.030-0.063mm | 320#:0.001-0.050mm |
Seen from the above chart, we know ceramic bead has the advantages of higher hardness, low dust generation,
longer service life,better blasting effect in visual sight compared with the one of glass beads,so ceramic beads
can replace galss beads where requires a clean and better blasting effect.
3. Product Features of Zirnano Ceramic Bead Blasting
Higher clearliness
Our ceramic bead are screened more than six times and blow-cleaning under high temperature,
which provides higher clearliness and ensures it to be work normally in humid weather;
More concentrated particle size distribution
B170(0.045-0.090μm),B205(0.045-0.063μm) is more concentrated than the other one(0-0.063μm) from other
company,which will achieve better blasting effect.
4. Main Applications of Ceramic Beads
B20&B30:Surface Sandblasting for metal Surface;
B40:Mold cleaning for glass bottles;
B60: surface cleaning for inner or outter wall of precision steel pipes;
B120: Surface finish for Golf club and artifical joint etc.
B170&B205: Surface finish for the metal surface of Iphone,Ipad,Ipod;
For more applications,please kindly review our other products of ceramic bead blasting.
5. Applicable Equipments:
Manual sand blasting machine;
Automatic sand blasting machine;
Open sand blasting machine;
Sandblasting room.
6. Why choose us?
Professional manufacturer of ceramic beads to provide stable products with most favorable price
Certificated by ISO9001,ISO14001
Products has already exported to Japan,Vietnam, USA, Russia,Poland,Taiwan Area etc.
The stable supplier of Foxconn,Samsung Electronics,Tongda Group etc.
7. How to use & store ceramic beads?
When using the ceramic beads,please wear protective equipments appropriately;
Avoid direct contact with eyes and skin;
Please wash hands with water and soap before eating, drinking and smoking;
Keep the container tightly closed and store it in a cool, dry warehouse
