Product Details:

Place of Origin: Shanxi,China
Brand Name: FUDA
Certification: ISO9001,ISO14001
Model Number: B20-B505

Payment & Shipping Terms:

Minimum Order Quantity: 100KGS
Price: Negotiation
Packaging Details: 2*12.5kg drum+Carton Box+pallet,25kg drum+pallet
Delivery Time: 3-10 days depending on the order quantity
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200mt per month
Get Best Price Contact Now

Detail Information

Product Name: Ceramic Bead Blasting Usage: Surface Finishing
Specification: B20-B505 Vicker Hardness: 700 HV
Bulk Density: 2.3g/cm3 True Gravity: ≥3.85g/cm3
High Light:

abrasive media blasting


low dust blasting media

Product Description

Consistent Blasting Effect Ceramic Bead Blasting Zirconium Oxide Ball B20-B505

1. Product Description

Ceramic Bead Blasting is also called as ceramic blasting beads or Zirconia Sand,it selects the high grade

zircon sand as raw material,then fused in electric furnace under high temperature over 2000 degrees then

made into different beads through special technology. It is widely used as one blasting media.

While there is the other similar ceramic bead,which is aslo called as zirconium silicate beads, is widely used

for grinding and dispersion media.

Here we just make a simple comparation between the above two ceramic beads as below:

Item Ceramic Blasting Beads Zirconium Silicate Beads
Chemical Index ZrO2 60-66%
SiO2 25-30%
Al2O3 7-13%
ZrO2 ≥65%
SiO2 25-30%
Others ≤1.0%
Processing Method Melting Sintering
Vickers Hardness ≥700 HV ≥900 HV
True Specific Gravity ≥3.85 g/cm3 ≥4.0g/cm3
Bulk Density ≥2.3g/cm3 ≥2.5g/cm3
Particle Size B20-B205 etc Φ0.1-10mm etc.
Usage Blasting Media Grinding Media


Seen from the above table,ceramic blasting beadshas different chemical index and physical index of hardness

and bulk density as well as different processing methods compared with the one of ziconium silicate beads.

Different properties decides their different applications.
2. Main Technical Index of Ceramic Bead Blasting Zirconia Sand

Particle Size
B20: 0.600-0.850mm B100: 0.125-0.180mm
B30: 0.425-0.600mm B120: 0.063-0.125mm
B40: 0.250-0.425mm B170: 0.045-0.090mm
B60: 0.125-0.250mm B205: 0.000-0.063mm
B80: 0.180-0.250mm B400: 0.030-0.063mm
Remark: Special specification can be customized


3. Product Features of Ceramic Bead Blasting Zirconia Sand

Little damage to the blasting equipment

Ceramic Beads is round and smooth, it could be rebounded in multi-angles and provides little damage

to the blasting equipment

No ferrous contamination

Ceramic Beads offers no ferrous contamination to the treatment surface,it is applid in the applications

where ferrous contamination is not allowed.

High Blasting Efficiency

Ceramic Beads has high hardness and good elasticity,it is not easy to be broken in

the whole blasting process,then offers lower abrasion rate. The worker does not need to refuel the beads

frequently,it finally improve the blasting efficiency.

Consistent Surface Finishing

Also due to the lower abrasion rate, the usage time of ceramic beads will last a longer blasting time,

then the beads in blasting equipment will be more stable,it will achieve more consistent surface finishing;

Clean working conditions

Ceramic Beads has lower dust, and there is no hidden danger of silicosis.

4. Main Application of Zirconia Ceramic Beads Blasting Media

Surface Finishing for 3C products such as the metal or plastic surface or its built-in parts of computer,

mobile phone,camera etc.;


Surface cleaning for various molds such as glass molds,tire molds,die molds etc.


Sandblasting for the Inner and outer wall of steel pipe,steel pipes etc


Shot peening for automotive and aviation components,such as aircraft engine blades, turbines etc.


Surface finish for medical instruments and golf clubs;

5. Product Package:

2*12.5kg drum+carton box+ pallet
25kg drum+pallet
Special packages can be customized.
B20 - B505 Ceramic Bead Blasting Consistent Blasting Effect High Hardness 0

6. Why Choose Us?


Professional Ceramic Beads manufacturer,Providing good products with stable quality & favorable price;


Equipped with the most advanced production line and testing equipments,certificatd by ISO9001&14001;


Being the stable supplier of Foxconn,Samsung,products has exported to USA,Vietnam,South Korea,Japan
