65 % Sintering Ceramic Grinding Media , Sphericity Ceramic Ball Mill Media
Product Details:
| Place of Origin: | Shanxi |
| Brand Name: | Fuda |
| Certification: | ISO9001&14001 |
| Model Number: | 0.1-50mm etc |
Payment & Shipping Terms:
| Minimum Order Quantity: | 25 KG |
|---|---|
| Price: | Negotiation |
| Packaging Details: | 25kg drum+ pallet， ton bag |
| Delivery Time: | 3-10 days depending on the order quantity |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000mt per year |
|
Detail Information |
|||
| Product Name: | Zirconia Beads | Usage: | Grinding Media |
|---|---|---|---|
| Material: | Zirconia | Shape: | Sphericity |
| Production Process: | Sintering | Particle Size: | Φ0.1-50mm |
| High Light: | ceramic grinding balls,ceramic ball mill media |
||
Product Description
95 Zirconia Ceramic Grinding Media 65% ZrO2 Zirconium Silicate Beads for Dispersion
1. Product Description of Zirconia Ceramic Grinding Media
Zironia Beads is produced by sintering process,it is widely used as one ceramic grinding media in various
industry.
It is generally divided into three kinds of zirconia beads according the different zirconia content:
95 Zirconia Beads(95Yttrium stabilized Zirconia beads),which contains 95% ZrO2
80 Zirconia Beads,which contains about 80% ZrO2
65 Zirconia Beads( zirconium silicate beads),which contains about 65% ZrO2
2. Main Technical Data of Zirconia Ceramic Grinding Media
| Item | 65 Zirconia Beads | 80 Zirconia Beads | 95 Zirconia Beads |
| Chemical Index | ZrO2 ≥65% SiO2 25-30% Others ≤1.0% |
ZrO2 ≥80% SiO2 ≥10% Al2O3≥9.0% |
ZrO2 ≥95% Y2O3 ≥4.5% Others ≤0.5% |
| Mohs Hardness | 8 Mohs | 9 Mohs | 9 Mohs |
| True Specific Gravity | ≥4.0g/cm3 | 5.2g/cm3 | ≥6.0 g/cm3 |
| Bulk Density | ≥2.5g/cm3 | 3.2g/cm3 | ≥3.7g/cm3 |
| Wear Rate Per Ton | 0.03kg/h | 0.02kg/h | 0.01kg/h |
| Particle Size | Φ0.1-10mm etc. | Φ0.6-2.2mm etc. | Φ0.1-50mm etc. |
| Grinding Usage | Low or Medium Viscosity slurry |
High Viscosity Slurry |
High Viscosity & Hardnes with zero pollution |
Seen from the above chart,95 zirconia has the higher hardness,bulk density and lower wear rate compared
with the one of 80 zirconia beads &65 zirconia beads.
3. The industry application of different zirconia beads
| Industry Type | Applicable Types of Zircona Beads |
| Ink Industry | 95 zirconia,65 Zirconia,80 Zirconia |
| Paint Industry | 95 zirconia,65 Zirconia,80 Zirconia |
| Coating Industry | 95 zirconia,65 Zirconia,80 Zirconia |
| Pigment | 95 zirconia,65 Zirconia,80 Zirconia |
| Dye | 95 zirconia,80 Zirconia |
| Pesticide | 95 zirconia,65 Zirconia,80 Zirconia |
| Titanium Dioxide | 95 zirconia,65 Zirconia,80 Zirconia |
| Electronic industry | 95 zirconia |
| Medical Industry | 95 zirconia |
| Non-metal Minerals | 95 zirconia,65 Zirconia,80 Zirconia |
4. Main Applications of Zirconium Silicate Beads
Zirconium Silicate Beads is widely used for grinding of ultrafine grinding of Pesticide such as Insecticides,
herbicides,fungicides and seed coatings.
In pesticide industry,zirconium silicate beads Φ1.8-2.0mm, Φ1.4. -1.6mm,Φ1.0-1.2mm and Φ1.4-1.6mm,
Φ1.0-1.2mm,Φ0.8-1.0mm are the most popular beads.
5. Product Package:
6.Why Choose Us?
Professional manufacturer,Providing good products with stable quality & favorable price;
Equipped with the most advanced production line and testing equipments,certificatd by
ISO9001&14001;
Products has been exported to USA,South Korea,Vietnam,Japan etc.
