Zirnano 62-66% Media Blasting Materials White Color For Magnesium Alloy
Product Details:
| Place of Origin: | China |
| Brand Name: | Zirnano |
| Certification: | ISO9001,ISO14001,ROHS,SGS |
| Model Number: | B20-B505 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100KGS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 25 KG (12L)Barrel + Pallet; 2*12.5 KG Barrel+ Carton Box+ Pallet |
| Delivery Time: | Within 3-5 days after order confirmed |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 3000 MTS Per Year |
|
Detail Information |
|||
| Commodity: | Ceramic Beads | Product Name: | Ceramic Beads Blasting |
|---|---|---|---|
| Vicker Hardness: | 700 HV | Application: | Blasting Media |
| Mohs Hardness: | 8 | Bulk Density: | 2.3 G/cm3 |
| True Gravity: | 3.85g/cm3 | Specification: | B60 150-300μm |
| High Light: | low dust blasting media,ceramic cleaning media |
||
Product Description
Zirnano 62-66% Ceramic Bead Blasting Media B60,B120,B205 for Magnesium Alloy
1. Product Description of Ceramic Bead Blasting Media
Ceramic Beads is one clean and high efficient blasting media,it has the same round solid shape as the
one of glass beads,while it is not easy to be broken in the blasting process and generate little dust, it
can replace glass beads in metal surface finish where one clean working condition is required.
2. Main Technical Data of Bead Blasting Media
| Commodity | Chemical Index | Physical Index |
| Ceramic Beads (Melting Process) |
ZrO2 60-66% | Bulk density:2.3g/cm3 |
| SiO2 25-30% | True Gravity ≥3.85 g/cm3 | |
| Al2O3 7-13% | Vicker Hardness≥700 HV | |
| Particle Size For Blasting Media |
B20:0.600-0.850mm | B100: 0.106-0.180mm |
| B30: 0.425-0.600mm | B120: 0.063-0.125mm | |
| B40: 0.250-0.425mm | B170: 0.045-0.090mm | |
| B60: 0.150-0.300mm | B205: 0.000-0.063mm | |
| B80: 0.125-0.212mm | B400: 0.030-0.063mm |
3. Why Ceramic beads can replace galss beads?
Compared with glass beads,ceramic beads has the following advantages:
- Stronger Impact Strength
Ceramic beads is wear -resistant,not easy to be broken, it will maintain the original shape,hardness,
smoothness,while glass beads will become to be dust after several cycles,even stick to the surface of
workpieces.
- Longer service life
Ceramic beads has low break-down rate,its service life will be prolonged 25-30 times than the one of glass
beads in wet blasting process.
- Better Blasting Effect
Ceramic beads will provide more consistent and shinny blasting effect.
- No solid waste disposal cost
Glass beads will finally break into dust,people have to spend addition cost to dispose it.
While no solid waste disposal cost when after using ceramic beads.
4. Main Applications of Ceramic Beads Blasting
B20,B30 for Metal Surface Finish
B40, B60 for glass-bottle mold cleaning,tire mold cleaning as well as die-cast aluminum
B120 for surface finish in artifical joint and golf club and other light alloy such as such as Magnesium alloy,
aluminum alloy ,titanium alloy
B170,B205 for surface finish in metal surface & built-in parts of 3C Products
5. The consumption contrast between Ceramic Beads & Glass Beads
| For the same Treated Parts | Blasting Media | Month Consumption | Solid Waste Q'ty | Total cost |
| Die-cast aluminum parts | Glass Beads 60# | 7.0mts | large quantity | High |
| Ceramic Beads B60 | 0.1mt | Small quantity | Low |
The above is one true testing result from our client,obviously ceramic beads has lower bead consumption,
it not only reduces the blasting cost and disposal cost of solid waste greatly,but also provides one clean
working condition for the operators.
6. Why Choose Us?
Higher clearliness
Our ceramic bead are screened more than six times and blow-cleaning under high temperature,which provides
higher clearliness and ensures it to be work normally in humid weather;
More concentrated particle size distribution
B170(0.045-0.090μm),B400(0.030-0.063μm) is more concentrated than the other one(0-0.063μm) from other
company,which will achieve better blasting effect.
More competitive price
Our plant is located in mountain area,which provides lower cost in environmental protection and workers’ salary,
then the product price Is more competitive than the one of other plants.
More flexible corporation model
No matter you are the distributor or final users,we will provide the more flexible payment term and corporation model.
