700HV Ceramic Blasting Media B40 B60 B120 B205 B505 Zirconia Beads
Product Details:
| Place of Origin: | China |
| Brand Name: | Zirnano |
| Certification: | ISO9001,ISO14001 |
| Model Number: | B20-B505 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100KGS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 25 kg barrel + Pallet |
| Delivery Time: | 3-5 days after order confirmed |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 200mts per month |
|
Detail Information |
|||
| Commodity: | Ceramic Blasting Media | Product Name: | Ceramic Beads |
|---|---|---|---|
| Usage: | Blasting Media | Chemical Index: | ZrO2 60-66%, SiO2 25-30%, Al2O3 7-13% |
| Vicker Hardness: | 700HV Min | Buck Density: | 2.2±0.1 G/cm3 |
| True Gravity: | ≥3.85g/cm3 | Sphericity: | 85% |
| High Light: | 700HV Ceramic Blasting Media,Ceramic Blasting Media B40 B60,B205 B505 Zirconia Beads |
||
Product Description
700HV 60 HRC Ceramic Blasting Media B40 B60 B120 B205 B505 for Tire Mould Cleaning
1. Product Description of Ceramic Blasting Media
Ceramic beads,glass beads,steel shots are three different popular blasting media,while ceramic beads
has unique advantage of high hardness,low breakdown rate to replace glass beads where more consistent
and shiny blasting effect as well as clean working condition is required. In addition,it also has medium density,
zero ferrous contamination to replace steel shots where ferrous contamination is prohibited.
It is one clean and high efficient blasting media,which not only provide low consumption as well as high visual
blasting effect.
2. Main Technical Data of Ceramic Beads
| Commodity | Process | Chemical Index | Physical Index |
| Ceramic Beads | Melting | ZrO2 60-66% | Bulk density:2.3g/cm3 |
| SiO2 25-30% | True Gravity ≥3.85 g/cm3 | ||
| Al2O3 7-13% | Vicker Hardness≥700 HV | ||
| Particle Size For Blasting Media |
B20:0.600-0.850mm | B120: 0.063-0.125mm | |
| B30: 0.425-0.600mm | B150: 0.053-0.106mm | ||
| B40: 0.250-0.425mm | B170: 0.045-0.090mm | ||
| B60: 0.125-0.250mm | B205: 0.000-0.063mm | ||
| B80: 0.180-0.250mm | B400: 0.030-0.063mm | ||
| B100: 0.125-0.180mm | B505: 0.010-0.030mm | ||
| Particle Size For Shot Peening |
Z100: 100-150μm | Z425:425-600μm | |
| Z150: 150-210μm | Z600: 600-850μm | ||
| Z210: 210-300μm | Z850: 850-1180μm | ||
| Z300: 300-425μm | / | ||
| Remark: Special specification can be customized | |||
3. Main Applications of Ceramic Beads
Surface Finsh for 3C Products and its accessories,artifical joint,medical instruments,stainless steel products,
plastic parts,precision machinery etc.
4. Main transportation Mode:
Air way if order quantity less than 100kgs
Sea way if order quantity more than 100kgs
5. Main Package of Ceramic Beads:
25KG(12L) Barrel + Pallet
2*12.5KG Barrel+ Carton + Pallet
25KG (12L) Barrel+ Wooden box or 2*12.5KG Barrel+ Carton+Pallet.
6. Why Choose Us?
Higher Cleanliness
All the ceramic beads are screened more than six times and blow-cleaning under high temperature,which
provides higher clearliness and ensures it to be work normally in humid weather;
Multiple Authentication
Certificated by ISO9001 ISO14001,SGS,ROHS
Stable Cooperation with World-renowned Companies
We are the stable supplier of Foxconn,Ujiden,Samsung Electronics,Tongda Group etc
Guaranteed Product Quality
All products is traceable from the very beginning of raw material to the final products,each shipment will be
tested even for one some quantity sample,providing good quality & stable performance
High price/performance Ratio
Our plant is located in mountain area,with competitive environmental costs and staff salaries,finally providing
more competitive price
Flexible Cooperation models
We provide flexible cooperation model and payment terms no matter you are the final users or distributor etc.
