ISO9001No Ferrous Contamination Ceramic Bead Blasting B80 For Aluminum Alloy ISO9001

Minimum Order Quantity : 100KGS Price : Negotiable
Packaging Details : 25kg barrel+pallet or 2*12.5kg barrel + Pallet Delivery Time : Within 3-5 days after order Confirmed
Payment Terms : L/C, T/T, Western Union, MoneyGram Supply Ability : 3000 MTS Per Year
Place of Origin: China Brand Name: Zirnano
Certification: ISO9001,ISO14001,ROHS,SGS Model Number: B20-B505

Detail Information

Specification: B20-B505 Sphericity: ≥ 80%
Commodity: Ceramic Blasting Media Product Name: Ceramic Beads
Mohs Hardness: 8 Mohs True Gravity: 3.85 G/cm3
Particle Range: 0-850 μm Vicker Hardness: 700HV
High Light:

abrasive blasting media


ceramic bead blasting media

Product Description

No Ferrous Contamination Ceramic Beads Blasting Media 20-B60,B80-B100,B120-B170,B205,B400,B505 for Aluminum Alloy



1. Product Description of Ceramic Beads Blasting Media


Ceramic beads is one popular blasting media,which is widely used in the surface treatment of aluminum parts.

After blasting, the surface of aluminum parts will achieve a certain degree of cleanliness and roughness, its

mechnical properties and anti-fatigue strength will be improved.

Ceramic beads is also used for surface finish of 3C products,light alloy,stainless steel,etc.


2. The Main Technical Data of  Ceramic Beads Blasting Media


Main Index of Ceramic Bead Blasting
ZrO2 SiO2 Al2O3
60-66% 25-30% 7-13%
Vicker Hardness True Specific Gravity Bulk Density
≥700 HV ≥3.85 g/cm3 2.3g/cm3


Particle Size
B20 B30 B40
600-850μm 425-600μm 250-425μm
B60 B80 B100
150-300μm 125-212μm 106-180μm
B120 B170 B205
63-125μm 45-90μm 0-63μm
B400 B505 /
30-63μm 0-30μm /


3. Main Features of Ceramic Beads Blasting Media

Good sphericity,smooth surface,high hardness;

Fine microstructure,low breakdown rate;

More consistent blasting effect;

Low disposal cost for solid waste;

No hidden danger of silicosis;

No contamination &Low damage to the blasting equipment & workpieces.


4. Main Applications  of Ceramic Bead Blasting Media

Surface Cleaning for impurity removal, rust removal,paint removal,scale removal,carbon deposition,weld bead,

machining tool marks etc;

Surface cleaning for glass-bottle molds,plastic molds,tire molds,die casting etc.;

Surface Finish for metal surface of 3C products and its built-in parts as well as accessories;

Surface Finish for Mechnical parts,medical instruments,golf head etc.

Pretreatment for electroplating,painting,anodizing etc.


5. Why choose Zirnano Ceramic Beads?

Higher clearliness

Our ceramic bead are screened more than six times and blow-cleaning under high temperature,

which provides higher clearliness and ensures it to be work normally in humid weather;


More Competitive price/performance Ratio

Our ceramic beads plant is located in mountain area,there is lower labor cost & environmental cost,then the

product cost is lower and more competitive than the one of others’ plants.


More stable quality

Our ceramic beads is made by high quality zircon sand according to stricter formula ratio,all the shipment

will be sampled and tested before loading.


6. The Comparation Effect before and after Sandblasting by Ceramic Beads

ISO9001No Ferrous Contamination Ceramic Bead Blasting B80 For Aluminum Alloy ISO9001 0


7. Package of Ceramic Beads Blasting Media:

2*12.5kg barrel+ Carton Box+Pallet

25kg barrel+ pallet

Special package can be customized

ISO9001No Ferrous Contamination Ceramic Bead Blasting B80 For Aluminum Alloy ISO9001 1
