Surface Treatment Ceramic Blasting Media Zirconia Beads B120 B170 B205

Minimum Order Quantity : 100KGS Price : Negotiable
Packaging Details : 2*12.5kg barrel+ carton box + pallet or 25kg barrel+pallet Delivery Time : 3-5 days after order confirmed
Payment Terms : L/C, T/T, Western Union, MoneyGram Supply Ability : 200mts per month
Place of Origin: China Brand Name: Zirnano
Certification: ISO9001,ISO14001 Model Number: B20-B400

Detail Information

Commodity: Ceramic Bead Blasting Product Name: Zirconia Beads
Usage: Blasting Media Blasting Effect: High Finish,No Discoloration
True Gravity: 3.85g/cm3 Bulk Density: 2.3 G/cm3
Shape: Solid Round Ball Color: White
High Light:

abrasive blasting media


ceramic bead blasting media

Product Description

Ceramic Blasting Media Zirconia Bead B20,B40,B60,B120,B170,B205 for Surface Treatment

1. Product Description of Ceramic Bead Blasting

Ceramic bead selects the high quality zirconium sand as material,fused in an electric furnace under high

temperature over 2000 degrees,then made into different micro beads through special technology.


The main chemical composition of ceramic beads is 62-66% ZrO2,,which determines that it will not generate

new ferrous contamination to the workpieces.

so It is widely used in many applicatons where ferrous contamination is prohibited.

2. The main Technical of Ceramic Bead Blasting

Main Index of Ceramic Bead Blasting
ZrO2 SiO2 Al2O3
60-66% 25-30% 7-13%
Vicker Hardness True Specific Gravity Bulk Density
≥700 HV ≥3.85 g/cm3 2.3g/cm3


Particle Size
B20: 0.600-0.850mm B100: 0.125-0.180mm
B30: 0.425-0.600mm B120: 0.063-0.125mm
B40: 0.250-0.425mm B170: 0.045-0.090mm
B60: 0.125-0.250mm B205: 0.000-0.063mm
B80: 0.180-0.250mm B400: 0.030-0.063mm
Remark: Special specification can be customized


3. Product Features of Ceramic Bead Blasting:

High Hardness,Good Impact Resistance;

High Efficiency and low energy consumption;

No Ferrous Contamination to the substrate material;

Low breakdown rate,High consistent blasting effect;

Superior smooth and visual effect.


4. Main Applications:

Surface finish for the metal surface and built-in parts of 3C products as well as USB,powder bank, earphones


Surface finish for precious metal, delicate medical instruments, artifical joint,golf club etc;

Surface cleaning for glass molds,plastic molds,die molds,castings etc;

Surface Preparation for electroplating, painting, anode etc., to remove impurities and increase the adhesion of

product surface.

Shot peening in aviation,ships,automotives,machinery industry to eliminate the stress,improve the extend

anti-fatigue life etc.

Surface Treatment Ceramic Blasting Media Zirconia Beads B120 B170 B205 0

5. Applicable Equipments:

Ceramic bead has wide range of particle size,it is able to be matched with many types of blasting equipment

from air pressure projection systems to wheel turbine machines.


6. Why Choose Us?

Professional manufacturer of ceramic beads to provide stable products with most favorable price

Certificated by ISO9001,ISO14001

Products has already exported to Japan,Vietnam, USA, Russia,Poland,Taiwan Area etc.

The stable supplier of Foxconn,Samsung Electronics,Tongda Group etc.
