Z600 Z425 Z300 Z210 Ceramic Shot Peening For Automotive And Aerospace Industry

Z600 Z425 Z300 Z210 Ceramic Shot Peening For Automotive And Aerospace Industry

Product Details:

Place of Origin: China
Brand Name: ZIRNANO
Certification: ISO9001,ISO14001
Model Number: Z100-Z850

Payment & Shipping Terms:

Minimum Order Quantity: 100KGS
Price: Negotiable
Packaging Details: 25KG Barrel + Pallet,2*12.5KG Barrel + Pallet
Delivery Time: 3-5 Days after order Confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 3000mt per Year
Get Best Price Contact Now

Detail Information

Commodity: Ceramic Shot Peening Product Name: Ceramic Shot
Usage: Shot Peening True Gravity: 3.85 G/cm3
Vicker Hardness: 700HV Bulk Density: 2.3 G/cm3
Shape: Solid Round Beads Size: Z100-Z850
High Light:

Z210 Ceramic Shot Peening

,

Z300 Ceramic Shot Peening

,

Z425 Ceramic Shot Peening

Product Description

Ceramic Shot Peening Z600 Z425 Z300 Z210 For Automotive and Aerospace Industry



1. Product Description of Ceramic Shot Peening



Ceramic shot peening selects the high quality imported zircon sand as main material,then fused in an

electric arc furnace under high temperature over 2000 degrees,finally made into different beads according

to AMS standard.



Ceramic shot peening is also round solid beads,while it has higher sphericity and more concentrated

particle size compared with ceramic beads.Then it is more expensive.



2. Main Technical of Ceramic Shot Peening




Ceramic Beads
ZrO2 60-66%
SiO2 25-30%
Al2O3 7-13%
Vickers Hardness ≥700 HV
Bulk Density≥2.3g/cm3
True Gravity: 3.85g/cm3
Process: Melting
Particle Size for Ceramic Shot Peening
Z100: 100-150μm Z150: 150-210μm
Z210: 210-300μm Z300: 300-425μm
Z425:425-600μm Z600: 600-850μm
Z850: 850-1180μm ./
Remark: Special specification can be customized.



3. Main Applications of Ceramic Shot Peeing



Manufacturing and maintenance of aerospace equipment such as titanium alloy materials

Automotive industry, such as the anti-fatigue and strengthening treatment for shock absorber spring

Turbine industry such as anti-fatigue treatment and strengthening treatment on the surface of turbine blades

Z600 Z425 Z300 Z210 Ceramic Shot Peening For Automotive And Aerospace Industry 0



4. The advantages of Ceramic Shot Peening



High hardness,smooth surface;



High strength and good impact resistance;



Small deformation to ensure the accuracy of the treatment;



Low breakdown rate;



No contamination to the treatments;



More consistent surface finish.



5. Packages of Shot Peening

25kg barrel+ Pallet;



2*12.5kg barrel+ Pallet;



25kg barrel+ Wooden Case;



Special package can be customized.
