Microspheres 700HV SS304 Ceramic Bead Blasting Media
Product Details:
Place of Origin: | China |
Brand Name: | Zirnano |
Certification: | ISO9001,ISO14001,SGS,ROHS |
Model Number: | B20-B505 |
Payment & Shipping Terms:
Minimum Order Quantity: | 100KGS |
---|---|
Price: | Negotiable |
Packaging Details: | 25kg barrel+pallet or 2*12.5kg barrel+carton+pallet |
Delivery Time: | 3-5 days after order confirmed |
Payment Terms: | L/C, T/T, Western Union, MoneyGram |
Supply Ability: | 250mts monthly |
Detail Information |
|||
Commodity: | Ceramic Blasting Media | Product Name: | Ceramic Beads Blasting |
---|---|---|---|
Color: | White | True Gravity: | 3.85g/cm3 |
Bulk Density: | 2.3g/cm3 | Hardness: | 700HV |
Sphericity: | ≥85% | Shape: | Round Solid Beads |
High Light: | SS304 Ceramic Bead Blasting Media,700HV Ceramic Bead Blasting Media,Ceramic Bead Blasting |
Product Description
Ceramic Blasting Media Micro Spheres B20 B40 B60 B120 B205 B400 for Surface Finish of 304 Stainless Stee
l
1. Product Description of Ceramic Beads Blasting
Ceramic Beads is also called as ceramic micro spheres,it selects the high quality imported zircon sand as main raw material,then fused in electric furnace,finally made into different beads by special technology.
Ceramic beads has lower density of steel shot, and higher density of glass beads,so it can make up their upper and lower blind area,then it can replace glass beads where one more delicate and lower roughness is required,or replace steel shot where ferrous contamination is prohibited.
So ceramic beads is one popular blasting media.
2. Main Technical Data of Ceramic Beads
Commodity | Main Chemical Index | Main Physical Index |
Ceramic Bead Blasting |
ZrO2 60-66% | Bulk Density: 2.3g/cm3 |
SiO2 25-30% | True Specific Gravity: 3.85 g/cm3 | |
Al2O3 7-13% | Vickers Hardness: 700 kg /mm2 | |
Particle Size (Ceramic Bead Blasting) |
B20: 0.600-0.850mm | B120: 0.063-0.125mm |
B30: 0.425-0.600mm | B150:0.000-0.125mm | |
B40: 0.250-0.425mm | B170: 0.045-0.090mm | |
B60: 0.150-0.300mm | B205: 0.000-0.063mm | |
B80: 0.125-0.212mm | B400: 0.030-0.063mm | |
B100: 0.106-0.180mm | B505: 0.010-0.030mm | |
Remark: Special specification can be customized |
3. Main Applications of Ceramic Beads
Metal surface finish for stainless steel,aluminum alloy, titanium alloy,magnesium alloy,die aluminum....
Surface Preparation before electroplating,anodizing etc
Shotpeening for automotive and aviation industries...
4. Precautions for using ceramic sand for the first time
When using ceramic beads blasting media for the first time,please kindly open 1/3 to 1/2 vest of dust collector,since ceramic beads need the wind to be recycled in the blasting process. It is different from other abrasives.
Please also kindly note that ceramic beads can be multiple recycled,its service life can be prolonged 20-30 times compared the one of glass beads.
Please pay attention to the quantity of ceramic beads or
its color in blasting machine, then refuel or replace it in time accordingly to ensure the good blasting effect.
5. Why choose us?
Our ceramic beads has higher cleanliness,all is screened 6 times and air-blow cleaned by special technology,the beads can be stored for a longer time and never humidity agglomeration;
Our plant located in mountain areas,products has more competitive price/performance ratio,since the environmental protection cost and salary cost is lower than the one of other plants.
The sphericity of ceramic beads(length/width ratio: 0.7) has reached to 85%
through continuous upgrading,which will provide better blasting effect.
7*24 hrs Professional sales and service team to provide prompt advice and consulting service.
Flexible payment terms and prompt delivery, products can be deliveried within 1-2 days after order confirmed.
Stable supplier of Foxconn,Samsung Electronics etc.
