• Good Impact Resistance Ceramic Shot Peening Z850 850 - 1180μM In Aviation Industry
  • Good Impact Resistance Ceramic Shot Peening Z850 850 - 1180μM In Aviation Industry
Good Impact Resistance Ceramic Shot Peening Z850 850 - 1180μM In Aviation Industry

Good Impact Resistance Ceramic Shot Peening Z850 850 - 1180μM In Aviation Industry

Product Details:

Place of Origin: China
Brand Name: Zirnano
Certification: ISO9001,ISO14001,ROHS,SGS
Model Number: Z100-Z850

Payment & Shipping Terms:

Minimum Order Quantity: 100KGS
Price: Negotiable
Packaging Details: 25 KG (12L)Barrel + Pallet; 2*12.5 KG Barrel+ Carton Box+ Pallet
Delivery Time: Within 3-5 days after order confirmed
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 3000 MTS Per Year
Get Best Price Contact Now

Detail Information

Commodity: Ceramic Shot Peening Product Name: Ceramic Beads
Application: Shot Peening Mohs Hardness: 8
Bulk Density: 2.3 G/cm3 True Gravity: 3.85g/cm3
Specification: Z425 850-1180μm Vicker Hardness: 700 HV
High Light:

shot blasting material

,

shot blasting abrasive

,

abrasive shot blasting

Product Description

Good impact resistance Ceramic Shot Peening Z850 850-1180μm in Avaiation Industry

1. Product Description of Ceramic Shot Peening

Ceramic Shot Peening also selects the zircon sand as main material and made into different beads through

special technology.





2. Main Technical Data of Ceramic Shot Peening

Commodity Main Chemical Index Main Physical Index

Ceramic Shot Peening
ZrO2 60-66% Bulk Density: 2.3g/cm3
SiO2 25-30% True Specific Gravity: 3.85 g/cm3
Al2O3 7-13% Vickers Hardness: 700 kg /mm2
Particle Size Z100: 100-150μm Z150: 150-210μm
Z210: 210-300μm Z300: 300-425μm
Z425:425-600μm Z600: 600-850μm
Z850: 850-1180μm
Remark: Special specification can be customized



3. Main Applications of Ceramic Shot Peening

In Shot Peening Application

Shot peening for mechnical components made by metallic alloys such as hard steel,titanium,aluminum...

to enhance the fragile resistance;



Shot Forming for aerospace structural components to shape and strengthen its slim hard alloys.

Good Impact Resistance Ceramic Shot Peening Z850 850 - 1180μM In Aviation Industry 0

In Blasting Applications:

Surface finish for 3C products,accessories,generator,Mechanical gear,Sanitary products as well as glass

bottle molds,tire molds,die casting etc.



Good Impact Resistance Ceramic Shot Peening Z850 850 - 1180μM In Aviation Industry 1

4. Main Features of Ceramic Shot Peening

High hardness and small deformation;



Fine microstructure and high strength,good impact resistance;



Low breakdown rate and no hidden danger of Silicosis.





5. How to calculate the media Peening (blasting) cost?



Media Peening (blasting) ​ Cost
Media Name Cycles %Breakdown
Glass Beads 9-12 10%
Ceramic Beads 70-90 1.20%
Steel shot 80-100 1%
Media Cost Per Hour=Hourly Delivery Rate*%Breakdown*cost per Lb.
Media Cost to Blast a Part=Media Cost Per Hour*Part cycle time(% of Hour)



6. Why Chooose us?

Professional Manufacturer of ceramic beads,annual output over 3000mts;



Equipped the most advanced production line,testing equipment, as well as professional technical staffs

and 7*24h technical support;



Strict quality control and quality assurance, products will be inspected by each shipment,even for the free

sample in small quantity;



Multiple Authentication,Certificated by ISO9001 ISO14001,SGS,ROHS;



Stable supplier of Foxconn,Ujiden,Samsung Electronics,Tongda Group etc.



Products in good quality & stable performance,competitive price,flexible payment terms,prompt delivery etc.
