95 Ceramic Zirconium Oxide Balls , White 0.1 - 0.2mm Zirconium Oxide Beads
Product Details:
| Place of Origin: | Shanxi |
| Brand Name: | Fuda |
| Certification: | ISO9001,ISO14001 |
| Model Number: | 0.1-50mm |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1kg |
|---|---|
| Price: | Negotiation |
| Packaging Details: | 25 kg drum+ pallet, Ton Bag |
| Delivery Time: | 3-10 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000 mt per year |
|
Detail Information |
|||
| Product Name: | 95 Zirconia Beads | Commodity: | Zirconia Oxide Ball |
|---|---|---|---|
| Vicker Hardness: | ≥1100HV | Mohs Hardness: | 9Mohs |
| True Gravity: | ≥6.0g/cm3 | Wear Rate Per Ton: | 0.01kg/h |
| High Light: | zirconium oxide beads,zirconia ceramic balls |
||
Product Description
95 Zirconia Oxide Ball Ceramic Grinding Media 0.1-0.2mm 0.6-0.8mm 1.0-1.2mm 1.0-1.2mm
1. Product Description of 95 Zirconia Oxide Ball Ceramic Grinding Media
95 Zirconia Oxide Ball is one kind of zirconia beads,it is also named as 95 Yttrium Stabilized
zirconia beads.
It is the most durable and efficient ceramic grinding media,which is used in ball mill to grind
or disperse various industrial slurries.
2. Main Technical Index of 95 Zirconia Oxide Ball Ceramic Grinding Media
| Item | 95 Zirconia Beads |
| Chemical Index | ZrO2 ≥95% Y2O3 ≥4.5% |
| Mohs Hardness | 9 Mohs |
| True Specific Gravity | ≥6.0 g/cm3 |
| Bulk Density | ≥3.7g/cm3 |
| Modulus of Elasticity | 210GPa |
| Fracture Toughness | 6.0MPam0.5 |
| Wear Rate Per Ton | 0.01kg/h |
| 95 Zirconia Beads Specification | |||
| Φ0.1-0.2mm | Φ0.2-0.3mm | Φ0.3-0.4mm | Φ0.4-0.6mm |
| Φ0.6-0.8mm | Φ0.8-1.0mm | Φ1.0-1.2mm | Φ1.2-1.4mm |
| Φ1.4-1.6mm | Φ1.6-1.8mm | Φ1.0-1.2mm | Φ2.0-2.2mm |
| Φ2.2-2.4mm | Φ2.4-2.6mm | Φ2.6-2.8mm | Φ2.8-3.0mm |
| Φ4mm | Φ5mm | Φ6mm | Φ7mm |
| Φ8mm | Φ9mm | Φ10mm | Φ12mm |
| Φ15mm | Φ17mm | Φ20mm | Φ25mm |
| Φ30mm | Φ40mm | Φ45mm | Φ50mm |
| Special Specification can be customized | |||
3. Main Features of 95 Zirconia Oxide Ball Ceramic Grinding Media
Low Wear Loss offers overall lower operation cost in long time grinding process.
Good sphericity and extremely smooth surface provides little damage to the sand mill.
High purity and white color prevents the cross-contamination between slurry and grinding media.
High mechnical strength and good impact resistence ensures no beads broken,reducing the refuel
times,improve the grinding effect
Anti acid and alkali
Its stable structure provides good acid and alkali resistence
4. Main Applications of 95 Zirconia Oxide Ball Ceramic Grinding Media
95 zirconia beads mainly used for various industries where minimal contamination is concerned,such
as nano materials,pharmaceutical,dental,food etc.
It is also used for high hardness materials such as electronic slurry including Fe batteries, ceramic slurry,
lithium battery etc.
In addition,it also has the same application as zirconium silicate beads in pigment,print,ink,coating,pesticide,
tatinium dioxide and non metal minerals.
5.Applicable Equipment:
Horizontal sand mill
Vertical sand mill
Basket sand mill
Ball mill
Vibration mill
