Zirconia Ceramic Abrasive Blasting Media
Product Details:
| Place of Origin: | Shanxi, China |
| Brand Name: | Zirnano |
| Certification: | ISO9001, ISO14001 |
| Model Number: | B100 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100KGS |
|---|---|
| Price: | Negotiation |
| Packaging Details: | 12.5kgs/barrel, 25kgs (2 barrels)/paper carton, or 25kgs barrels +pallet |
| Delivery Time: | 5-10 days |
| Supply Ability: | 1500mt per year |
|
Detail Information |
|||
| Commodity Name: | Zirconia Ceramic Blasting Media | Chemical Index: | ZrO2 62-66% |
|---|---|---|---|
| Manufacturing Process: | Melting In Furnace | Bulk Density: | 2.3g/cm3 |
| True Density: | 3.85g/cm3 | Hardness: | 700HV |
| Package: | 25kgs (12 L) Barrels +pallet | ||
| High Light: | abrasive media blasting,ceramic cleaning media |
||
Product Description
Ceramic bead blasting for Mobile phone and computer metal frame sandblasting
Ceramic beads blasting media is a spherical micro bead produced by electro-fusion process with dense crystal structure. Zirconium crystals in a glassy silicon dioxide cover, and this structure leads the ceramic beads of high density and high shock resistance, not easy to reform and break, so ensures its surface finishing consistency
| Product | Process | Specific Density | Bulk Density | Vickers Hardness |
| Ceramic beads | Electro-fusing | 3.85 (g/cm³) | 2.3 (g/cm³) | 700 HV |
| Chemical Components | ZrO2 62-68% | SiO2 25-30% | Al2O3 7-13% | Other 1% Max. |
| Size Available (mm) |
Blasting-clean/Surface finish | Shot peening | ||
| B20: 0.600-0.850mm | Z150: 0.150-0.210mm, | |||
| B30: 0.425-0.600mm | Z210: 0.210-0.300mm | |||
| B40: 0.250-0.425mm | Z300: 0.300-0.425mm, | |||
| B60: 0.125-0.250mm | Z425: 0.425-0.600mm, | |||
| B80: 0.180-0.250mm | Z600: 0.600-0.850mm | |||
| B100: 0.128-0.18mm | Z850:0.850-1.180mm | |||
| B120: 0.063-0.125mm | Other sizes can be customized against customers’ requirement. | |||
| B170: 0.045-0.090mm | ||||
| B205 : 0.000-0.063mm | ||||
| B400: 0.000-0.063mm | ||||
- 1. High hardness and small deformation ensures surface consistency.
- 2. High density and high strength, leads high blasting efficiency
- 3. Applicable for various materials like stainless steel, aluminum alloys and titanium alloys, etc.
- 4. Low breaking rate and no dust
- Mobile phone and computer metal frame sandblasting
- Full range of metal inserts and external parts blasted
- Golf head surface treatment
- Sandblasting inside and outside the steel pipe
- Glass mold, tire mold blast cleaning
-
Shot peening ferrous and non ferrous items including aircraft engine blades, blisks, turbines etc.
- Ceramic beads are easy to handle in all categories of air or wet pressure blasting equipment including pneumatic blasting rooms.
- Also well suited for working in most kinds of wheel turbine blasting machines.
